DJI P4 Multispectral

Kataloški broj: DJI-P4M

Garancija
Plaćanje karticom
Dostava
Pakiranje

14,569.90 KM

  • Multispectral Imaging System
  • Live NDVI View
  • RTK Module
  • TimeSync

Dostupno na upit

Opis

Takeoff Weight :
  • 1487 g
Diagonal Distance (Propellers Excluded) :
  • 350 mm
Max Service Ceiling Above Sea Level :
  • 6000 m
Max Ascent Speed :
  • 6 m/s (automatic flight); 5 m/s (manual control)
Max Descent Speed :
  • 3 m/s
Max Speed :
  • 31 mph (50 kph) (P-mode); 36 mph (58 kph) (A-mode)
Max Flight Time :
  • Approx. 27 minutes
Operating Temperature :
  • 0° to 40° C
Operating Frequency :
  • 2.4000 GHz to 2.4835 GHz (Europe, Japan, Korea)
  • 5.725 GHz to 5.850 GHz (Other countries/regions
Transmission Power (EIRP) :
  • 2.4 GHz: < 20 dBm (CE / MIC / KCC)
  • 5.8 GHz: < 26 dBm (FCC / SRRC / NCC)
Hover Accuracy Range :
  • RTK enabled and functioning properly:
  • Vertical: ± 0.1 m; Horizontal: ± 0.1 m
  • RTK disabled:
  • Vertical: ± 0.1 m (with vision positioning); ± 0.5 m (with GNSS positioning)
  • Horizontal: ± 0.3 m (with vision positioning); ± 1.5 m (with GNSS positioning)
Image Position Compensation :
  • The relative positions of the centers of the six cameras’ CMOS and the phase center of the onboard D-RTK antenna have been calibrated and are recorded in the EXIF data of each image.
Single-Frequency High-Sensitivity GNSS :
  • GPS + BeiDou + Galileo[2] (Asia); GPS + GLONASS + Galileo[2] (other regions)
Multi-Frequency Multi-System High-Precision RTK GNSS :
  • Frequency Used
  • GPS: L1/L2; GLONASS: L1/L2; BeiDou: B1/B2; Galileo[2]: E1/E5
  • First-Fixed Time: < 50 s
  • Positioning Accuracy: Vertical 1.5 cm + 1 ppm (RMS); Horizontal 1 cm + 1 ppm (RMS).
  • 1 ppm indicates error with a 1 mm increase over 1 km of movement.
  • Velocity Accuracy: 0.03 m/s
Ground Sample Distance (GSD) :
  • (H/18.9) cm/pixel, H indicates the aircraft altitude relative to the area mapped (unit: m)
Rate of Data Collection :
  • Max operating area of approx. 0.47 km2 for a single flight at an altitude of 180 m, i.e., GSD is approx. 9.52 cm/pixel
Controllable Range :
  • Tilt: -90° to +30°
Velocity Range :
  • ≤ 31 mph (50 kph) at 6.6 ft (2 m) above ground with adequate lighting
Altitude Range :
  • 0 - 33 ft (0 - 10 m)
Operating Range :
  • 0 - 33 ft (0 - 10 m)
Obstacle Sensory Range :
  • 2 - 98 ft (0.7 - 30 m)
Operating Environment :
  • Surfaces with clear patterns and adequate lighting (> 15 lux)
Sensors :
  • Six 1/2.9” CMOS, including one RGB sensor for visible light imaging and five monochrome sensors for multispectral imaging.
  • Each Sensor: Effective pixels 2.08 MP (2.12 MP in total)
Filters :
  • Blue (B): 450 nm ± 16 nm; Green (G): 560 nm ± 16 nm; Red (R): 650 nm ± 16 nm; Red edge (RE): 730 nm ± 16 nm; Near-infrared (NIR): 840 nm ± 26 nm
Lenses :
  • FOV (Field of View): 62.7°
  • Focal Length: 5.74 mm (35 mm format equivalent: 40 mm), autofocus set at ∞
  • Aperture: f/2.2
RGB Sensor ISO Range :
  • 200 - 800
Monochrome Sensor Gain :
  • 1 - 8x
Electronic Global Shutter :
  • 1/100 - 1/20000 s (visible light imaging); 1/100 - 1/10000 s (multispectral imaging)
Max Image Size :
  • 1600×1300 (4:3.25)
Photo Format :
  • JPEG (visible light imaging) + TIFF (multispectral imaging)
Supported File Systems :
  • FAT32 (£ 32 GB); exFAT (> 32 GB)
Supported SD Cards :
  • microSD with a minimum write speed of 15 MB/s. Max Capacity: 128 GB. Class 10 or UHS-1 rating required
Operating Temperature :
  • 0° to 40° C
Operating Frequency :
  • 2.4000 GHz to 2.4835 GHz (Europe, Japan, Korea)
  • 5.725 GHz to 5.850 GHz (Other countries/regions)
Transmission Power (EIRP) :
  • 2.4 GHz: < 20 dBm (CE / MIC / KCC)
  • 5.8 GHz: < 26 dBm (FCC / SRRC / NCC)
Max Transmission Distance :
  • FCC / NCC: 4.3 mi (7 km)
  • CE / MIC / KCC / SRRC: 3.1 mi (5 km)(Unobstructed, free of interference)
Built-in Battery :
  • 6000 mAh LiPo 2S
Operating Current / Voltage :
  • 1.2 A @ 7.4 V
Mobile Device Holder :
  • Tablets and smartphones
Operating Temperature :
  • 0° to 40° C
Capacity :
  • 5870 mAh
Voltage :
  • 15.2 V
Battery Type :
  • LiPo 4S
Energy :
  • 89.2 Wh
Net Weight :
  • 468 g
Operating Temperature :
  • -10° to 40° C
Charging Temperature :
  • 5° to 40° C
Max Charging Power :
  • 160 W
Voltage :
  • 17.5 V
Operating Temperature :
  • 5° to 40° C
Voltage :
  • 17.4 V
Rated Power :
  • 160 W
