DJI Matrice 300 RTK


Garancija
Plaćanje karticom
Dostava
Pakiranje

  • 15 km Max Transmission
  • 55-min Max Flight Time
  • 6 Directional Sensing & Positioning
  • Primary Flight Display
  • IP45 Rating

Opis

AIRCRAFT
    Dimensions :
    • Unfolded, propellers excluded, 810×670×430 mm (L×W×H)
    • Folded, propellers included, 430×420×430 mm (L×W×H)
    Diagonal Wheelbase :
    • 895 mm
    Weight (with single downward gimbal) :
    • Approx. 3.6 kg (without batteries)
    • Approx. 6.3 kg (with two TB60 batteries)
    Max Payload :
    • 2.7 kg
    Max Takeoff Weight :
    • 9 kg
    Operating Frequency :
    • 2.4000-2.4835 GHz
    • 5.725-5.850 GHz
    EIRP :
    • 2.4000-2.4835 GHz:
    • 29.5 dBm (FCC); 18.5dBm (CE)
    • 18.5 dBm (SRRC); 18.5dBm (MIC)
    • 5.725-5.850 GHz:
    • 28.5 dBm (FCC); 12.5dBm (CE)
    • 28.5 dBm (SRRC)
    Hovering Accuracy (P-mode with GPS)
    • Vertical:
    • ±0.1 m (Vision System enabled)
    • ±0.5 m (GPS enabled)
    • ±0.1 m (RTK enabled)
    • Horizontal:
    • ±0.3 m (Vision System enabled)
    • ±1.5 m (GPS enabled)
    • ±0.1 m (RTK enabled)
    RTK Positioning Accuracy :
    • When RTK enabled and fixed:
    • 1 cm+1 ppm (Horizontal)
    • 1.5 cm + 1 ppm (Vertical)
    Max Angular Velocity :
    • Pitch: 300°/s, Yaw: 100°/s
    Max Pitch Angle :
    • 30° (P-mode, Forward Vision System enabled: 25°)
    Max Ascent Speed :
    • S mode: 6 m/s
    • P mode：5 m/s
    Max Descent Speed (vertical) :
    • S mode: 5 m/s
    • P mode：3 m/s
    Max Descent Speed (tilt) :
    • S Mode: 7 m/s
    Max Speed :
    • S mode: 23 m/s
    • P mode：17 m/s
    Service Ceiling Above Sea Level :
    • 5000 m (with 2110 propellers, takeoff weight ≤ 7 kg) / 7000 m (with 2195 propellers, takeoff weight ≤ 7 kg)
    Max Wind Resistance :
    • 15 m/s
    Max Flight Time :
    • 55 min
    Supported DJI Gimbals :
    • Zenmuse XT2/XT S/Z30/H20/H20T
    Supported Gimbal Configurations :
    • Single Downward Gimbal, Dual Downward Gimbals, Single Upward Gimbal, Upward and Downward Gimbals, Triple Gimbals
    Ingress Protection Rating :
    • IP45
    GNSS :
    • GPS+GLONASS+BeiDou+Galileo
    Operating Temperature :
    • -20°C to 50°C (-4°F to 122° F)
    REMOTE CONTROLLER
      Operating Frequency :
      • 2.4000-2.4835 GHz
      • 5.725-5.850 GHz
      Max Transmitting Distance (unobstructed, free of interference) :
      • NCC/FCC: 15 km
      • CE/MIC: 8 km
      • SRRC: 8 km
      EIRP :
      • 2.4000-2.4835 GHz:
      • 29.5 dBm (FCC) 18.5dBm (CE)
      • 18.5 dBm (SRRC); 18.5dBm (MIC)
      • 5.725-5.850 GHz:
      • 28.5 dBm (FCC); 12.5dBm (CE)
      • 20.5 dBm (SRRC)
      External battery :
      • Name: WB37 Intelligent Battery
      • Capacity: 4920 mAh
      • Voltage: 7.6V
      • Type: LiPo
      • Energy: 37.39Wh
      • Charging time (using BS60 Intelligent Battery Station): 70 minutes (15°C to 45°C); 130 minutes (0°C to 15°C)
      Built-in battery :
      • Type: 18650 lithium ion battery (5000 mAh @ 7.2 V)
      • Charging: Use a USB charger with specification of 12V / 2A
      • Rated power: 17 W
      • Charging time: 2 hours and 15 minutes (Using a USB charger with specification of 12V / 2A)
      Battery Life :
      • Built-in battery: Approx. 2.5h
      • Built-in battery+External battery: Approx. 4.5h
      USB Power Supply :
      • 5 V / 1.5 A
      Operating Temperature :
      • -20°C to 40°C (-4 °F to 104 °F)
      VISION SYSTEM
        Obstacle Sensing Range :
        • Forward/Backward/Left/Right: 0.7-40m
        • Upward/Downward: 0.6-30m
        FOV :
        • Forward/Backward/Downward: 65° (H), 50° (V)
        • Left/Right/Upward: 75°(H), 60°(V)
        Operating Environment :
        • Surfaces with clear patterns and adequate lighting (> 15 lux)
        INFRARED TOF SENSING SYSTEM
          Obstacle Sensing Range :
          • 0.1-8m
          FOV :
          • 30° (±15°)
          Operating Environment :
          • Large, diffuse and reflective obstacles (reflectivity >10%)
          TOP AND BOTTOM AUXILIARY LIGHT
            Effective lighting distance :
            • 5 m
            FPV CAMERA
              Resolution :
              • 960p
              FOV :
              • 145°
              Frame rate :
              • 30 fps
              INTELLIGENT FLIGHT BATTERY
                Name :
                • TB60
                Capacity :
                • 5935 mAh
                Voltage :
                • 52.8 V
                Battery Type :
                • LiPo 12S
                Energy :
                • 274 Wh
                Net Weight :
                • Approx. 1.35 kg
                Operating Temperature :
                • -4°F to 122°F (-20°C to 50°C)
                Ideal storage temperature :
                • 71.6°F to 86°F (22°C to 30°C)
                Charging Temperature :
                • -4°F to 104°F (-20°C to 40°C)
                • (When the temperature is lower than 5°C, the self-heating function will be automatically enabled. Charging in a low temperature may shorten the lifetime of the battery)
                Charging time :
                • Using BS60 Intelligent Battery Station:
                • 220V input: 60 minutes (fully charging two TB60 batteries), 30 minutes (charging two TB60 batteries from 20% to 90%)
                • 110V input: 70 minutes (fully charging two TB60 batteries), 40 minutes (charging two TB60 batteries from 20% to 90%)
                BS60 INTELLIGENT BATTERY STATION
                  Dimensions :
                  • 501*403*252mm
                  Net Weight :
                  • 8.37kg
                  Maximum Capacity :
                  • TB60 Intelligent Flight Battery × 8
                  • WB37 Intelligent Battery × 4
                  Input :
                  • 100-120 VAC, 50-60 Hz / 220-240 VAC, 50-60 Hz
                  Max. Input Power :
                  • 1070W
                  Output Power :
                  • 100-120 V: 750 W
                  • 220-240 V: 992 W
                  Operating Temperature :
                  • -4°F to 104°F (-20°C to 40°C)
                  IN THE BOX :
                  • Aircraft Body x1
                  • DJI Smart Controller Enterprise x1
                  • USB Charger x1
                  • USB-C Cable x1
                  • TB60 Intelligent Flight Battery x2
                  • WB37 Intelligent Battery x1
                  • 2110 Propeller (CW) x2
                  • Landing Gear x2
                  • Spare Stick Cover (pair) x1
                  • Spare Propeller Holder x2
                  • Spare Gimbal Damper x4
                  • USB Cable (with Double A Ports) x1
                  • Vision System Calibration Plate x1
                  • Carrying Case x1
                  • Smart Controller Lanyard x1
                  • Rubber Port Cover (Set) x1
                  • MScrews and Tools x1
                  • BS60 Battery Station x1
                  • Power Lead x1

                  Brand

                  DJI
